| Težina | 0,6 kg |
|---|
Opis
• For comparing flows in cooling and heating systems
• Combined manual valve with pre-set
• Joint internal thread
Technical data:
• Max. static operating pressure: 25 bar
• Min. temperatures: -10 °C
• Nominal pressure: PN25
• Fluid: Water and glycols
• Material: Brass (dezincification-resistant)
• O-rings: EPDM Perox
• With two measuring valves for measuring needles
• Handwheel with shut-off function and easily readable 360° digit display
• Max. flow temperature: 150°C
• Fixed measuring orifice, accuracy of measurement ± 5%
Recenzije (0)
Samo prijavljeni kupci koji su kupili ovaj proizvod mogu napisati recenziju.
Dostupne opcije
| Veličina | Šifra | Cijena | Količina | |
|---|---|---|---|---|
| DN 25 (1”) | 60,78 € | |||
| DN 15 (1/2" | 9086218 | 60,78 € | ||
| DN 20 (3/4") | 9086219 | 72,69 € | ||
| DN 32 (1 1/4") | 9086220 | 111,09 € | ||
| DN 40 (1 1/2") | 9086222 | 156,10 € | ||
| DN 50 (2”) | 9086223 | 219,01 € |
